層光顯微鏡

儀器名稱:

Zeiss Lightsheet Z.1


儀器功能:

  • Multi-channel confocal fluorescence image acquisition
  • 3D image acquisition & processing
  • Timelapse image acquisition
  • Multiview acquisition
  • Tile Scan acquisition
  • Pivot Scan

儀器配備:


Items

Specification

SoftwareZEN 2014 for Lightsheet
ZEN 2014 Processing Package for Lightsheet
3D VisArt module
Deconvolution module
Arivis Vision4D for Zeiss
MicroscopeStandDual side illumination body
Objective

Detection optics:

EC Plan-NEOFLUAR 5x/0.16
W Plan-APOCHROMAT 20x/1.0

Illumination optics:

5x/0.1
10x/0.2

Culture systemTempModule S1
TempModule CZ-LSFM
CO2-Module
Heating Device Humidity S1
Light sheetLaser Device405 nm (50 mW)
445 nm (40 mW)
488 nm (50 mW)
515 nm (50 mW)
561 nm (50 mW)
638 nm (75 mW)
Fl. EM. FilterDAPI--- BP 420-470
CFP--- BP 460-500
GFP--- BP 505-545
YFP--- BP 525-565 or BP 525-545
RFP--- BP 575-615
Cy5--- LP 660
DetectorCMOS---PCO.Edge, 1920x1920 (x2)



儀器照片:
