轉盤式顯微鏡
儀器名稱：
Andor Dragonfly 202
儀器功能：
- Multi-channel confocal fluorescence image acquisition
- 3D image acquisition & processing
- Timelapse image acquisition
- Tile Scan acquisition
- SRRF high resolution acquisition
儀器配備：
Items | Specification | |
| Software | Fusion Real-time 3D visualization ClearView Deconvolution app. Imaris | |
| Microscope | Stand | Motorized inverted microscope XY Scanning Stage Auto Focus Control |
| Objective | PL APO 10X / 0.45 PL APO 20X / 0.8 PL APO 40X / 1.10 W CORR PL APO 40X / 1.3 oil PL APO 63X / 1.2 W CORR PL APO 63X / 1.4-0.6 oil PL APO 100X / 1.44 oil PL APO 20X / 0.75 IMM CORR PL APO 40X / 1.25 GLYC CORR PL APO 63X / 1.3 GLYC CORR PL FL 10X / 0.32 PH1 PL FL 20X / 0.4 CORR 0-2 PH1 PL FL 40X / 0.6 CORR 0-2 PH2 | |
| Fl. Light source | SOLA SM 365 | |
| Fl. Filter | Filter cube DAPI Filter cube FITC Filter cube TRITC Filter cube Cy5 Filter cube CFP Filter cube YFP | |
| Culture system | LCI living cell incubation system, include: Chamlide TC-A CU501 controller FC-5 gas mixer | |
| Spinning Disk Confocal | Laser Device | 405 nm (100 mW) 445 nm (75 mW) 488 nm (150 mW) 514 nm (150 mW) 561 nm (150 mW) 637 nm (140 mW) |
| Fl. EM. Filter | DAPI--- BP 422-468 CFP--- BP 460-497 GFP--- BP 505-550 YFP--- BP 525-555 RFP--- BP 572-615 Cy5--- LP 660-737 | |
| Detector | sCMOS---Sona 4.2B-6 USB, 2048x2048 (x2) | |
儀器照片：
