Liquid Chromatography-Triple Quadrupole Mass Spectrometry (Sciex 6500+)

Mass range: m/z 50–2,000

TQ scan speed: 12000 Da/sec

LIT scan speed: 20000 Da/sec

Gas Chromatography-Triple Quadrupole Mass Spectrometry (Shimadzu GC-TQ8050 NX)

Mass range: m/z 10-1090

Quad scan speed: 20000 Da/sec

MS Resolution: up to 2700

800 MRM transitions/second

Dwell time: 0.5 msec

Liquid Chromatography Q-Orbitrap/LIT tribrid (Thermo Fusion Lumos Tribrid)

Mass range:

m/z 50–2,000

m/z 200–4,000 (High mass mode)

up to m/z 6,000 without precursor ion selection (OTMS only)

OTMS Resolution: 7500-500000 FWHM at m/z 200

Scan rate:

OTMSn up to 30 Hz

ITMSn up to 40 Hz

Mass Accuracy <2ppm

MALDI TOF/TOF  (Autoflex maX)

Mass range: m/z 100-500000

Scan rate: 2000 Hz

FWHM≥ 26,000, at m/z 3147
